4U Server Cooler for Intel LGA4677 / 4710
153mm height, 2x 120mm Fan, 6 Copper Heatpipes, TDP 425W
High-performance active 4U cooler for Intel Xeon LGA4677 / 4710 CPUs, supporting up to 425W TDP. It features aluminium fins, six copper heatpipes, and dual 120mm PWM fans for efficient and reliable cooling, ideal for demanding server environments.
Active 4U Cooler for Intel Xeon (LGA4677 / 4710 Socket)
Designed for extreme cooling needs. This 4U cooler is built for Intel Xeon CPUs on LGA4677 sockets, providing high-performance cooling for database and security like environments.
Aluminium Fins with Six Copper Heatpipes
Maximised heat dissipation. The aluminium fins combined with six copper heatpipes effectively transfer heat away from the CPU, ensuring it stays cool under heavy server workloads.
425W TDP Cooling Capacity
Powerful cooling for demanding applications. This cooler supports Intel Xeon Platinum CPUs up to 425W TDP, offering reliable performance for intensive server tasks.
Dual 120mm x 28.5mm PWM Fans with Two Ball Bearings
Advanced airflow and durability. Equipped with two 120mm PWM fans, the cooler delivers 72.68 CFM of airflow at speeds ranging from 1000-2200 RPM. Two ball bearings ensure a long-lasting fan life of up to 80,000 hours.
Includes E1B Carrier (LGA4677) for Easy Installation
Quick and secure setup for 4U server systems. Includes mounting screws and an E1B package carrier.
Note: LGA4677 processors with E1A/E1C carriers and LGA4710 processors with E2A/E2B carriers require separate plastic CPU carrier frames for installation (typically included with boxed processors or available separately through Intel® vendors/carrier suppliers for tray processors).
| Socket Type | LGA4677, LGA4710 |
|---|---|
| Solution | 4U Server |
| Suggestion TDP(W) | 425 |
| Cooler Dimensions | 120 x 135 x 153 mm |
| Material | Aluminium fin with six copper heatpipes |
| Installation | Mounting screw (include E1B CPU carrier) |
| Weight | 1262g |
| Thermal Interface | Pre-apply |
| Product Code | AK-CC9502BP01 |
| Dimensions | 120 x 120 x 28.5 mm x2 pcs (Cable Length: 300 mm) |
|---|---|
| Bearing | Two ball bearing |
| Fan Speed | 1000-2200 RPM |
| Max Airflow | 72.68 CFM |
| Max Air Pressure | 3.18 mm-H2O |
| Noise Level | 36 dB(A) (Max) |
| Fan Rated Current | 0.16A (Max:0.2A) |
| Fan Rated Voltage | DC 12V |
| Connector | 4-Pin PWM (2510 connector) |
| Fan Life Expectancy | 80,000 hours |
| Warranty | 2 years |
