Pascal NE
IP65 Waterproof Fanless Case for the Intel® NUC Board Element (Butler Beach)
Compact IP65 aluminium fanless case for the Intel® NUC Board Element (Butler Beach) and compatible Intel® NUC Compute Elements (U-Series). Perfect chassis for digital signage, kiosks, security surveillance to POS requiring IP protection.
|
Pascal NE
IP65 Waterproof fanless case
for Intel® NUC Board Element (Butler Beach)
and compatible Intel® NUC Compute Elements (U-Series)
Create a Compact and Versatile System
Build with the Intel® NUC Compute Element powered by Core i7 or i5 with vPro, for a compact and upgradeable computing solution. With a selection of I/O's - perfect for an array of applications
including digital signage, kiosks, security surveillance to POS requiring additional chassis protection.
IP65 Protection Design
IP65 rating provides protection against dust and low pressure
water jets. Designed for Modular Computing
with Modular Features Compact aluminium chassis designed for the modular Intel® NUC Board Element (Butler Beach) with the corresponding Intel® NUC Compute Elements (U-Series).
Modular
Modular waterproof connectors.
Power adapter cable, USB3.0 cable, HDMI cable and network cable included (length: 2m) Excellent Heat Dissipation Technology
Aluminium fanless cooling design
Array of Applications
Perfect chassis as a small form
factor,
powerful system with IP65 protection for outdoor digital signage, kiosks, security surveillance to POS applications. |
| Material | Aluminium |
|---|---|
| Motherboard Types & Support | (1) Intel® NUC 12 Compute Element (U-Series) (Hard Bay): ELM12HBv7 with Intel® Core™ i7 vPro® ELM12HBi7 with Intel® Core™ i7 ELM12HBv5 with Intel® Core™ i5 vPro® ELM12HBi5 with Intel® Core™ i5 ELM12HBi3 with Intel® Core™ i3 ELM12HBC with Intel® Celeron® (2) Intel® NUC 11 Compute Element (U-Series) (Elk Bay): CM11EBv716W with Intel® Core™ i7 vPro® CM11EBi716W with Intel® Core™ i7 CM11EBv58W with Intel® Core™ i5 vPro® CM11EBi58W with Intel® Core™ i5 CM11EBi34W with Intel® Core™ i3 CM11EBC4W with Intel® Celeron® (3) Intel® NUC 8 Compute Element (U-Series) (Chandler Bay): CM8v7CB with Intel® Core™ i7 vPro® CM8i7CB with Intel® Core™ i7 CM8v5CB with Intel® Core™ i5 vPro® CM8i5CB with Intel® Core™ i5 CM8i3CB with Intel® Core™ i3 CM8PCB with Intel® Pentium® Gold CM8CCB with Intel® Celeron® |
| Maximum TDP Support | 15W |
| Dimensions | 150 (W) x260(D) x 54(H)mm |
| Cooling System | Passive |
| Power Supply (optional) | External 19V, 100-240V AC |
| Baseboard / Carrier Board | CMB1BB (Butler Beach Board Element) or customised |
| Front I/O opening | Customisable |
| Cables | Power adapter cable USB3.0 or USB2.0 cable HDMI cable Network cable |
| Cable length | 2m |
| Product code | A-NUC57-M1B |
