Maze | ALUMINIUM CASE for Raspberry Pi 4 Model B with power button and thermal kit

Maze

PASSIVE
ALUMINIUM CASE

for Raspberry Pi 4 Model B

Dual Solid Aluminium Cores

Embedded dual solid aluminium cores coupled with hi-performance
thermal pads conducts excess heat away from the key hot zones
of the processor and power management regulators to the
aluminium body. Keeping your Raspberry Pi 4 cool and running
smoothly without thermal throttling.

Superb Cooling Performance

Excess heat from the dual aluminium core is effectively transferred
to the all aluminium body which acts as a heatsink to dissipate
the heat to the surrounding. Ensuring the Pi runs at optimal
thermal performance, even under higher loads.

Contemporary and Made-to-Last Design

Solid aluminium case provides durability and long-lasting use. With
striking Maze-like design for stunning aesthetics and functionality,
which means the case look great in any environment.

Reprogrammable Power Button

Reprogrammable and convenient power button to easily power on
and off the system without having to remove the power source from
the Pi 4.

Perfect Feature for Commercial Applications

Concealed SD card for commercial systems production where access
post-system production is not required.

Easy Connector Accessibility

Full I/0 support including GPIO, Ethernet, USB, camera and
display connectors. Purpose-designed Wi-Fi signal window to
optimise Wi-Fi and Bluetooth signal connection.

Material	Blackanodised aluminium
Dimensions	97 x 65.5 x 35 mm
Motherboard Support	Raspberry Pi 4 Model B
Input/Output Openings	Type-C power supply x 1 Micro HDMI x 2 Stereo audio & composite video x 1 Dual USB 2.0 x 1 Dual USB 3.0 x 1 Ethernet x 1 LED x 2 Wi-Fi signal window x 1 GPIO x 1 Camera module x 1 Display module x 1
Additional Input/Output	Reprogrammable Power Button
Concealed Openings	MicroSD
Product Code	A-RA10-M1B
