Galileo TU1 Plus MKII

1U Fanless Thin Mini-ITX Case

• Premium aluminium fanless CPU cooling design
• LGA1700 ready
• Two internal 2.5'' SSD/HDD bay
• Two bay 2.5'' SATA mobile tray
• Supports one low-profile PCIe card (8X)
• Optional rackmount front panel
• Wide application
• Added support for industrial motherboards

Added Support for Industrial Motherboards

Supported industrial motherboards:

- Asrock IMB-1233-WV
- Asrock IMB-1222
- Asrock IMB-1223

See more supported motherboards in the specification

Premium Brushed Aluminium

Premium aluminium case for hi-heat dissipation and durability. Brushed finish for a sleek and stylish look.

Intel® LGA1700 Ready

Perfect for the Intel® Alder Lake processors up to 35W Thermal Design Point (TDP) with increased contact surface area, allowing for more heat to be dissipated at a time.

Abundance of Storage Space

Two 2.5" SATA mobile tray bays at the front of the case coupled with internal space for two additional 2.5'' SATA drives for plentiful storage capability.

Rack Mountable

Perfect for server, broadcasting and audiophile applications.

Low-Profile PCIe Expansion

Supports one low-profile PCIe card (8x).

Multiport USB Connection

Two front panel USB 3.2 Gen 1 and two USB 2.0 ports for added connectivity.

Superb Cooling Performance

Completely silent premium aluminium Thin Mini-ITX case with hi-efficient passive thermal module and hi-performance dual copper heatpipes. Transfers the heat from the processor to the fins on the exterior of the case, in order for the heat to be dissipated to the surroundings.

Space Saving

1U in profile height with volume of 5.2L

Express Your Branding & Identity

Optional bespoke engraving and colouring solutions to highlight and differentiate your fanless system solution. Requires a minimum order quantity - please talk to our Team about the different options available.

Contact Us >

Material Aluminium with anodised black
Motherboard Types Thin mini-ITX with DC onboard
Socket Support Intel® LGA1700/1200/115X
Maximum TDP Support 35W
Dimensions 482.6 x 278 x 43.6mm ( W x D x H )
Drive Bays Two internal 2.5" HDD / SSD bays (max height 9.5mm)
Two bay 2.5" SATA mobile tray (max height 9.5mm)
Front I/O USB 3.2 Gen 1 x2, USB 2.0 x2, Power button, Power & hard drive LEDs, Mobile tray x2
Rear I/O Low profile PCI-E slot x1 (8X)
Antenna Fitting Holes 2
Security Kensington lock
VESA Mounting Support
Product Code A-ITX52-M1BV2

Installation manual


- 2023-10-05
