Galileo TU2 Plus
1U Fanless Thin Mini-ITX Case for Intel® LGA1700
Slim 1U fanless thin mini-ITX case. Massive storage with room for four internal 2.5'' drives. Sleek design mixed with hi-dissipation thanks to the premium aluminum.
|
Galileo TU2 Plus
1U Rackmount
Fanless Thin Mini-ITX Case • Premium aluminium fanless CPU cooling design
• LGA1700 ready • Four internal 2.5" HDD / SSD bay • Supports one low-profile PCIe card (x4) • Optional rackmount front panel • Wide application Premium Brushed Aluminium
Premium aluminium case for hi-heat dissipation and durability. Brushed finish for a sleek and stylish look. Intel® LGA1700 Ready
Perfect for low-powered T-series Intel® Alder Lake processors up to 35W Thermal Design Point (TDP). Featuring an upgrade thermal module to cater for increased contact surface area and mounting pattern for LGA1700. Abundance of Storage Space
Four internal 2.5" HDD/SSD mobile bays for plentiful storage capability.
Optional 1U Rackmount Front Panel
1U rackmount front panel available to mount the Galileo TU2 Plus case on a rack or cabinet. Perfect for server, broadcasting and audiophile applications. Lo-Profile PCIe Expansion
Supports one low-profile PCIe card (x4).
Multiport USB Connection
Two front panel USB 3.2 Gen 1 and two USB 2.0 ports for added connectivity. Superb Cooling Performance
Completely silent premium aluminium Thin Mini-ITX case with hi-efficient passive thermal module and hi-performance dual copper heatpipes. Transfers the heat from the processor to the fins on the exterior of the case, in order for the heat to be dissipated to the surroundings. Space Saving
1U in profile height with volume of 5.2L |
| Material | Aluminium with anodised black |
|---|---|
| Motherboard Types | Thin mini-ITX with DC onboard |
| Socket Support | Intel® LGA1700/1200/115X |
| Maximum TDP Support | 35W |
| Dimensions | 430 x 278 x 43.1 mm ( W x D x H ) |
| Drive Bays | Four internal 2.5" HDD / SSD bays (max height of 15.1 mm) |
| Front I/O | USB 3.2 Gen 1 x2, USB 2.0 x2, Power button, Power & hard drive LEDs |
| Rear I/O | Low profile PCI-E slot x1 (x4) |
| Antenna Fitting Holes | 2 |
| Security | Kensington lock |
| VESA Mounting | Support |
| Product Code | A-ITX53-M1B |
